Description

Our Hi-Speed USB to RS232 adapters make it quick and simple to connect RS232 devices to a USB port on your computer. These adapters use Hi-Speed USB for reduced latency and improved throughput. RS232 is widely used in a range of legacy and new equipment, but most computers don’t have physical RS232 ports nowadays. With a variety of port numbers and enclosure styles and easy to install drivers for a range of operating systems, these adapters are ideal for adding one or more RS232 ports to your computer.

• Based on the renowned FTDI Hi-Speed USB-Serial chipsets and drivers
• Compact and robust design in a variety of metal and plastic enclosure styles
• Microsoft Windows® WHQL-certified, macOS, Linux and Windows CE device drivers
• Each RS232 port can appear as a Virtual Com Port allowing easy use with existing application programs
• Multi-port units create a separate COM port for each RS232 port with separate settings (such as baud rate and flow control) per port
• Ports can also be accessed using the FTDI D2xx DLL functions
• RS232 via DB-9 Male connector (and terminal block on 1- and 2-port metal models)
• Automatic Hardware (RTS / CTS) and software (X-on/X-off) flow control
• Transmit and Receive LED indicators help to confirm operation and assist in troubleshooting
• Available in 1, 2, 4, 8, 16 and 32-port versions
• 1, 2 and 4-port models powered from the USB port (no external power needed)
• Optional 5V power out on some models
• USB 2.0 Hi-Speed (compatible with all USB ports including USB3)
• Wall mount brackets included (1, 2, 4, 8 port versions)
• -40°C to 85°C extended operating temperature range
• The product comes complete with free downloadable drivers for Microsoft and MAC OS platforms.
• Linux kernel 2.4.20 or greater includes USB drivers for this product downloadable for free.
• CE/FCC approved
• Industrial options available

Feel free to browse through the corresponding datasheet for more information.
